- FORTIGATE 60E
- Hardware Specifications :
- GE RJ45 WAN / DMZ Ports : 2 / 1
- GE RJ45 Internal Ports : 7
- GE RJ45 PoE/+ Ports : 0
- Wireless Interface : 0
- USB Ports : 1
- Console (RJ45 ) : 1
- Internal Storage : 0
- FORTIGATE 60E-POE
- Hardware Specifications :
- GE RJ45 WAN / DMZ Ports : 2
- GE RJ45 Internal Ports : 0
- GE RJ45 PoE/+ Ports : 8
- Wireless Interface : 0
- USB Ports : 1
- Console (RJ45) : 1
- Internal Storage : 0
- FORTIWIFI 60E
- Hardware Specifications :
- GE RJ45 WAN / DMZ Ports :2 / 1
- GE RJ45 Internal Ports : 7
- GE RJ45 PoE/+ Ports : 0
- Wireless Interface : 802.11 a/b/g/n/ac
- USB Ports : 1
- Console (RJ45) : 1
- Internal Storage : 0
- FORTIGATE 61E
- Hardware Specifications :
- GE RJ45 WAN / DMZ Ports : 2 / 1
- GE RJ45 Internal Ports : 7
- GE RJ45 PoE/+ Ports : 0
- Wireless Interface : 0
- USB Ports : 1
- Console (RJ45) : 1
- Internal Storage : 1x 128 GB SSD
- FORTIWIFI 61E
- Hardware Specifications :
- GE RJ45 WAN / DMZ Ports : 2 / 1
- GE RJ45 Internal Ports : 7
- GE RJ45 PoE/+ Ports : 0
- Wireless Interface : 802.11 a/b/g/n/ac
- USB Ports : 1
- Console (RJ45) : 1
- Internal Storage : 1x 128 GB SSD
- System Performance — Enterprise Traffic Mix :
- IPS Throughput : 400 Mbps
- NGFW Throughput : 250 Mbps
- Threat Protection Throughput : 200 Mbps
- System Performance:
- Firewall Throughput (1518 / 512 / 64 byte UDP packets) : 3 / 3 / 3 Gbps
- Firewall Latency (64 byte UDP packets) : 3 ?s
- Firewall Throughput (Packets Per Second) : 4.5 Mpps
- Concurrent Sessions (TCP) : 1.3 Million
- New Sessions/Second (TCP) : 30,000
- Firewall Policies : 5,000
- IPsec VPN Throughput (512 byte) : 2 Gbps
- Gateway-to-Gateway IPsec VPN Tunnels : 200
- Client-to-Gateway IPsec VPN Tunnels : 500
- SSL-VPN Throughput : 150 Mbps
- Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) : 200
- SSL Inspection Throughput (IPS, avg. HTTPS) : 135 Mbps
- SSL Inspection CPS (IPS, avg. HTTPS) : 135
- SSL Inspection Concurrent Session (IPS, avg. HTTPS) : 75,000
- Application Control Throughput (HTTP 64K) : 650 Mbps
- CAPWAP Throughput (HTTP 64K) : 890 Mbps
- Virtual Domains (Default / Maximum) : 10 / 10
- Maximum Number of FortiSwitches Supported : 16
- Maximum Number of FortiAPs (Total / Tunnel Mode) : 30 / 10
- Maximum Number of FortiTokens : 500
- High Availability Configurations : Active / Active, Active / Passive, Clustering
- Dimensions
- Height x Width x Length (inches) 1.5 x 8.5 x 6.3
- Height x Width x Length (mm) 38 x 216 x 160
- Weight 1.9 lbs (0.9 kg)
- Form Factor : Desktop
- Hardware Specifications
- GE RJ45 Switch Ports : 5
- GE RJ45 WAN Ports : 2
- USB Ports : 1
- Console (RJ45) : 1
- System Performance — Enterprise Traffic Mix :
- IPS Throughput : 350 Mbps
- NGFW Throughput : 220 Mbps
- Threat Protection Throughput : 160 Mbps
- System Performance :
- Firewall Throughput : 2.5 Gbps
- Firewall Latency (64 byte UDP packets) : 180 ?s
- Firewall Throughput (Packets Per Second): 375 Kpps
- Concurrent Sessions (TCP) : 1.8 Million
- New Sessions/Second (TCP) : 21,000
- Firewall Policies : 5,000
- IPsec VPN Throughput (512 byte) : 90 Mbps
- Gateway-to-Gateway IPsec VPN Tunnels : 200
- Client-to-Gateway IPsec VPN Tunnels : 250
- SSL-VPN Throughput : 100 Mbps
- Concurrent SS-VPN Users (Recommended Maximum, Tunnel Mode) : 200
- SSL Inspection Throughput (IPS, avg. HTTPS) : 150 Mbps
- SSL Inspection CPS (IPS, avg. HTTPS) : 140
- SSL Inspection Concurrent Session (IPS, avg. HTTPS) : 75,000
- Application CoLntrol Throughput (HTTP 64K) : 450 Mbps
- CAPWAP Throughput (HTTP 64K) : 1.2 Gbps
- Virtual Domains (Default / Maximum) : 5 / 5
- Maximum Number of FortiSwitches Supported : 8
- Maximum Number of FortiAPs (Total / Tunnel Mode) : 10 / 5
- Maximum Number of FortiTokens : 500
- High Availability Configurations : Active/Active, Active/Passive, Clustering
- Dimensions :
- Height x Width x Length (inches) : 1.44 x 8.52 x 5.5
- Height x Width x Length (mm) : 36.5 x 216 x 140
- Weight : 2.015 lbs(0.914 kg)
- Form Factor : Desktop
- FORTIGATE 60F
- Hardware Specifications :
- GE RJ45 WAN / DMZ Ports : 2 / 1
- GE RJ45 Internal Ports : 7
- GE RJ45 FortiLink Ports : 2
- Wireless Interface : 0
- USB Ports : 1
- Console (RJ45) : 1
- Internal Storage : 0
- FORTIGATE 61F
- Hardware Specifications
- GE RJ45 WAN / DMZ Ports : 2 / 1
- GE RJ45 Internal Ports : 7
- GE RJ45 FortiLink Ports : 2
- Wireless Interface : 0
- USB Ports : 1
- Console (RJ45) : 1
- Internal Storage : 1 x 128 GB SSD
- FORTIWIFI 60F
- Hardware Specifications
- GE RJ45 WAN / DMZ Ports : 2 / 1
- GE RJ45 Internal Ports 7
- GE RJ45 FortiLink Ports 2
- Wireless Interface : 802.11 a/b/g/n/ac-W2
- USB Ports : 1
- Console (RJ45) : 1
- Internal Storage : 0
- FORTIWIFI 61F
- Hardware Specifications
- GE RJ45 WAN / DMZ Ports : 2 / 1
- GE RJ45 Internal Ports : 7
- GE RJ45 FortiLink Ports : 2
- Wireless Interface : 802.11 a/b/g/n/ac-W2
- USB Ports : 1
- Console (RJ45) : 1
- Internal Storage : 1 x 128 GB SSD
- System Performance — Enterprise Traffic Mix :
- IPS Throughput : 1.4 Gbps
- NGFW Throughput : 1 Gbps
- Threat Protection Throughput : 700 Mbps
- System Performance :
- Firewall Throughput(1518 / 512 / 64 byte UDP packets) : 10/10/6 Gbps
- Firewall Latency (64 byte UDP packets) : 4 ?s
- Firewall Throughput (Packets Per Second) : 9 Mpps
- Concurrent Sessions (TCP) : 700,000
- New Sessions/Second (TCP) : 35,000
- Firewall Policies : 5,000
- IPsec VPN Throughput (512 byte) : 6.5 Gbps
- Gateway-to-Gateway IPsec VPN Tunnels : 200
- Client-to-Gateway IPsec VPN Tunnels : 500
- SSL-VPN Thro 9ughput :00 Mbps
- Concurrent SSL-VPN Users(Recommended Maximum, Tunnel Mode) : 200
- SSL Inspection Throughput(IPS, avg. HTTPS) : 750 Mbps
- SSL Inspection CPS (IPS, avg. HTTPS) : 400
- SSL Inspection Concurrent Session (IPS, avg. HTTPS) : 55,000
- Application Control Throughput (HTTP 64K) : 1.8 Gbps
- CAPWAP Throughput (HTTP 64K) : 8 Gbps
- Virtual Domains (Default / Maximum) : 10 / 10
- Maximum Number of FortiSwitches Supported : 16
- Maximum Number of FortiAPs (Total / Tunnel Mode) : 30 / 10
- Maximum Number of FortiTokens : 500
- High Availability Configurations : Active / Active, Active / Passive, Clustering
- Dimensions :
- Height x Width x Length (inches) : 1.5 x 8.5 x 6.3
- Height x Width x Length (mm) : 38.5 x 216 x 160 mm
- Weight : 2.23 lbs (1.01 kg)
- Form Factor : Desktop
- Brand: Fortinet
- Model: FortiGate-60E
- Item Weight: 1.74 Kg
- Package Dimensions: 30.5 x 21.1 x 12.2 cm
- Item model number: FortiGate 60E
- Batteries Included: No
- Batteries Required: No
- Brand: Fortinet
- Model: FG-80E-BDL
- Item Weight: 1.2 Kg
- Product Dimensions: 17.8 x 21.6 x 4.2 cm
- Item model number: FG-80E-BDL
- Operating System: None
- Colour Screen: No
- Wattage: 20 Watts
- Batteries Included: No
- Batteries Required: No
- Wireless Type: 802.11abg
- Firewall Throughput (1518/512/64 byte UDP): 5 / 5 / 5 Gbps
- IPsec VPN Throughput (512 byte) 1: 4.4 Gbps
- IPS Throughput (Enterprise Mix) 2: 1 Gbps
- NGFW Throughput (Enterprise Mix) 2, 4: 800 Mbps
- Threat Protection Throughput (Ent. Mix) 2, 5: 600 Mbps
- Firewall Latency: 4 µs
- Concurrent Sessions: 700,000
- New Sessions/Sec: 35,000 Firewall Policies :5,000
- Max G/W to G/W IPSEC Tunnels: 200
- Max Client to G/W IPSEC Tunnels: 250
- SSL VPN Throughput: 490 Mbps
- Concurrent SSL VPN Users (Recommended Maximum, Tunnel Mode): 200
- SSL Inspection Throughput (IPS, avg. HTTPS) 3: 310 Mbps
- Application Control Throughput (HTTP 64K) 2: 990 Mbps
- Max FortiAPs (Total / Tunnel): 10 / 5
- Max FortiSwitches: 8
- Max FortiTokens: 500
- Virtual Domains ( Default/Max): 10 / 10
- Interfaces: 5x GE RJ45
- Power Supplies: Single AC PS
- Form Factor: Desktop
- Firewall Throughput (1518/512/64 byte UDP): 0.95 Gbps
- IPsec VPN Throughput (512 byte) 1: 75 Mbps
- IPS Throughput (Enterprise Mix) 2: 300 Mbps
- NGFW Throughput (Enterprise Mix) 2, 4: 200 Mbps
- Threat Protection Throughput (Ent. Mix) 2, 5: 150 Mbps
- Firewall Latency: 130 µs
- Concurrent Sessions: 900,000
- New Sessions/Sec: 15000
- Firewall Policies: 5000
- Max G/W to G/W IPSEC Tunnels: 200
- Max Client to G/W IPSEC Tunnels: 250
- SSL VPN Throughput: 35 Mbps
- Concurrent SSL VPN Users (Recommended Maximum, Tunnel Mode): 100
- SSL Inspection Throughput (IPS, avg. HTTPS) 3: 125 Mbps
- Application Control Throughput (HTTP 64K) 2: 400 Mbps
- Max FortiAPs (Total / Tunnel): 2 / 2
- Max FortiSwitches: 8
- Max FortiTokens: 500
- Virtual Domains ( Default/Max): 5 / 5
- Interfaces: 5x GE RJ45
- Power Supplies: Single AC PS
- Form Factor: Desktop
- Variants: WiFi, 3G4G, LENC
- Interfaces: 4 x 2.5-GbE SFP, 4 x 2.5-GbE, 12 x 1-GbE, 1 GbE Management Console
- Management : CLI, SSH, GUI, GMS
- Nodes Supported : Unrestricted
- RAM : 2 GB
- Site-to-Site VPN Tunnels : 1,000
- Global VPN Clients (Maximum) : 50 (1,000)
- SSL VPN NetExtender Clients (Maximum) : 2 (350)
- VLAN Interfaces : 256
- SonicPoints Wireless Controller : Standard
- WWAN Failover (4G/LTE) : Standard
- Network Switch Management : Standard
- Firewall Inspection Throughput : 3.0 Gbps
- Full DPI Throughput (GAV/GAS/IPS) : 600 Mbps
- Application Inspection Throughput : 1.4 Gbps
- IPS Throughput : 1.4 Gbps
- Anti-Malware Inspection Throughput : 600 Mbps
- IMIX Throughput : 700 Mbps
- SSL DPI Throughput : 300 Mbps
- VPN Throughput : 1.5 Gbps
- Latency : 38 ?s
- Maximum SPI Connections : 1M
- Maximum DPI Connections : 500K
- Default/Maximum Connections (DPI SSL) : 12,000/13,500
- New Connections/Sec : 15,000
- Logging and Reporting : Analyzer, Local Log, Syslog
- Network Traffic Visualization : Standard
- Netflow/IPFIX Reporting : Standard
- SNMP : Standard
- Authentication : LDAP (multiple domains), XAUTH/RADIUS, SSO, Novell, Terminal Services, Citrix
- Dynamic Routing : BGP, OSPF, RIP
- Firewall Throughput : 2.5Gbps
- UTM Throughput : 550Mbps
- IPS Throughput : 1.25Gbps
- AV Throughput : 550Mbps
- IMIX Throughput : 850Mbps
- VPN Throughput : 550Mbps
- Concurrent SPI Connections : 50,000
- Concurrent DPI Connections : 50,000
- New Connections per Second : 5,000
- SSL Inspection / Decryption : 750Mbps
- Get Industry-leading Performance with the Firebox T70
- Many organizations today are dependent on fast, reliable and secure Internet connectivity, but are struggling to find network security solutions that can keep up with their ever growing needs. While many rack-mount solutions can keep up with today’s fastest fiber-to-the-premises speeds, there are not currently any tabletop security appliances available that have this capability, especially when running with additional security services enabled. This makes it difficult for SMBs and distributed enterprises to harness these powerful Internet speeds with the complete UTM protection they require.
- Includes a one (1) year standard support licence subscription.
- Boosts five (5) Gigabit Ethernet RJ45 LAN interfaces.
- No need to compromise protection for strong performance or vice versa.
- Support high-speed LAN backbone infrastructures and Gigabit WAN connections.
- Best-of-breed security components into one platform for stronger security at big cost savings.
- Firewall throughput up to 1Gbps and VPN throughput upto 360Mbps to keep traffic moving.
- Brings enterprise-level network security to small offices and retail environments.
- Cloud-based RapidDeploy technology taking the delay out of the firewall deployment process.
- Allows small businesses to have access to enterprise-grade security.
- Wireless versions of the T35 and T55 use 802.11ac operating in the 2.4 GHz and 5GHz bands for high performance and superior reliability.
- All logging and reporting functions included with purchase, with over 100 dashboards and reports including PCI and HIPAA.
- 5 Gigabit Ethernet ports support high-speed LAN backbone infrastructures & gigabit WAN connections.
- PoE port to power a peripheral device such as a WatchGuard Secure Wi-Fi Access Point, allowing administrators to extend the reach of their networks without having to run costly AC power to the remote device.
- Wireless versions of the T35 and T55 use 802.11ac operating in the 2.4 GHz and 5GHz bands for high performance and superior reliability.
- All logging and reporting functions included with purchase, with over 100 dashboards and reports including PCI and HIPAA.
- 5 Gigabit Ethernet ports support high-speed LAN backbone infrastructures & gigabit WAN connections.
- PoE port to power a peripheral device such as a WatchGuard Secure Wi-Fi Access Point, allowing administrators to extend the reach of their networks without having to run costly AC power to the remote device.
- Wireless versions of the T35 and T55 use 802.11ac operating in the 2.4 GHz and 5GHz bands for high performance and superior reliability.
- All logging and reporting functions included with purchase, with over 100 dashboards and reports including PCI and HIPAA.
- 5 Gigabit Ethernet ports support high-speed LAN backbone infrastructures & gigabit WAN connections.
- PoE port to power a peripheral device such as a WatchGuard Secure Wi-Fi Access Point, allowing administrators to extend the reach of their networks without having to run costly AC power to the remote device.
- Ideal for Small office/home office and small retail environments
- Recommended User Count: 5
- Firewall Throughput: 400 Mbps
- VPN Throughput: 150 Mbps
- UTM Throughput: 90 Mbps
- Concurrent Sessions: 100,000
- 1 Year Standard Support
- CRiV-2C (Support upto 2 vCPU)
- CRiV-4C (Support upto 4 vCPU)
- CRiV-8C (Support upto 8 vCPU)
- CRiV-12C (Support upto 12 vCPU)
- VMware ESX/ESXi
- VMware Workstation
- VMware Player
- Hyper-V
- KVM
- Citrix XenServer
- CRiV-2C (Support upto 2 vCPU)
- CRiV-4C (Support upto 4 vCPU)
- CRiV-8C (Support upto 8 vCPU)
- CRiV-12C (Support upto 12 vCPU)
- VMware ESX/ESXi
- VMware Workstation
- VMware Player
- Hyper-V
- KVM
- Citrix XenServer
- Flexible network connectivity with I/O slots and Flexi Ports
- Supports Copper, Fiber 1GbE/10GbE connectivity options
- Easy, cost-effective upgrade to new technologies
- Consolidates number of network devices, offering reduced complexity, power efficiency, less operational costs
- Flexibility to choose network connectivity options ensures lower costs today and investment protection in future
- Flexible network connectivity with I/O slots and Flexi Ports
- Supports Copper, Fiber 1GbE/10GbE connectivity options
- Easy, cost-effective upgrade to new technologies
- Consolidates number of network devices, offering reduced complexity, power efficiency, less operational costs
- Flexibility to choose network connectivity options ensures lower costs today and investment protection in future
- 14x10/100/1000 Ethernet ports
- 4x1GbE SFP(Mini GBIC) Ports
- 2 x 10GbE SFP(Mini GBIC) Ports
- 36000 Mbps Firewall Throughput
- 4000 Mbps UTM Throughput
- Flexible network connectivity with I/O slots and Flexi Ports
- Supports Copper, Fiber 1GbE/10GbE connectivity options
- Easy, cost-effective upgrade to new technologies
- Consolidates number of network devices, offering reduced complexity, power efficiency, less operational costs
- Flexibility to choose network connectivity options ensures lower costs today and investment protection in future
- Flexible network connectivity with I/O slots and Flexi Ports
- Supports Copper, Fiber 1GbE/10GbE connectivity options
- Easy, cost-effective upgrade to new technologies
- Consolidates number of network devices, offering reduced complexity, power efficiency, less operational costs
- Flexibility to choose network connectivity options ensures lower costs today and investment protection in future
- Flexible network connectivity with I/O slots and Flexi Ports
- Supports Copper, Fiber 1GbE/10GbE connectivity options
- Easy, cost-effective upgrade to new technologies
- Consolidates number of network devices, offering reduced complexity, power efficiency, less operational costs
- Flexibility to choose network connectivity options ensures lower costs today and investment protection in future
- Site-to-site and remote access VPN and advanced clustering provide highly secure, high-performance access and high availability to help ensure business continuity.
- Granular Application Visibility and Control (AVC) supports more than 3,000 application-layer and risk-based controls that can launch tailored intrusion prevention system (IPS) threat detection policies to optimize security effectiveness.
- The industry-leading Cisco ASA with FirePOWER next-generation IPS (NGIPS) provides highly effective threat prevention and full contextual awareness of users, infrastructure, applications, and content to detect multivector threats and automate defense response.
- Reputation- and category-based URL filtering offer comprehensive alerting and control over suspicious web traffic and enforce policies on hundreds of millions of URLs in more than 80 categories.
- AMP provides industry-leading breach detection effectiveness, a low total cost of ownership, and superior protection value that helps you discover, understand, and stop malware and emerging threats missed by other security layers.
- Site-to-site and remote access VPN and advanced clustering provide highly secure, high-performance access and high availability to help ensure business continuity.
- Granular Application Visibility and Control (AVC) supports more than 3,000 application-layer and risk-based controls that can launch tailored intrusion prevention system (IPS) threat detection policies to optimize security effectiveness.
- The industry-leading Cisco ASA with FirePOWER next-generation IPS (NGIPS) provides highly effective threat prevention and full contextual awareness of users, infrastructure, applications, and content to detect multivector threats and automate defense response.
- Reputation- and category-based URL filtering offer comprehensive alerting and control over suspicious web traffic and enforce policies on hundreds of millions of URLs in more than 80 categories.
- AMP provides industry-leading breach detection effectiveness, a low total cost of ownership, and superior protection value that helps you discover, understand, and stop malware and emerging threats missed by other security layers.
- Site-to-site and remote access VPN and advanced clustering provide highly secure, high-performance access and high availability to help ensure business continuity.
- Granular Application Visibility and Control (AVC) supports more than 3,000 application-layer and risk-based controls that can launch tailored intrusion prevention system (IPS) threat detection policies to optimize security effectiveness.
- The industry-leading Cisco ASA with FirePOWER next-generation IPS (NGIPS) provides highly effective threat prevention and full contextual awareness of users, infrastructure, applications, and content to detect multivector threats and automate defense response.
- Reputation- and category-based URL filtering offer comprehensive alerting and control over suspicious web traffic and enforce policies on hundreds of millions of URLs in more than 80 categories.
- AMP provides industry-leading breach detection effectiveness, a low total cost of ownership, and superior protection value that helps you discover, understand, and stop malware and emerging threats missed by other security layers.
- Site-to-site and remote access VPN and advanced clustering provide highly secure, high-performance access and high availability to help ensure business continuity.
- Granular Application Visibility and Control (AVC) supports more than 3,000 application-layer and risk-based controls that can launch tailored intrusion prevention system (IPS) threat detection policies to optimize security effectiveness.
- The industry-leading Cisco ASA with FirePOWER next-generation IPS (NGIPS) provides highly effective threat prevention and full contextual awareness of users, infrastructure, applications, and content to detect multivector threats and automate defense response.
- Reputation- and category-based URL filtering offer comprehensive alerting and control over suspicious web traffic and enforce policies on hundreds of millions of URLs in more than 80 categories.
- AMP provides industry-leading breach detection effectiveness, a low total cost of ownership, and superior protection value that helps you discover, understand, and stop malware and emerging threats missed by other security layers.
- Cisco ASA with FirePOWER Services is centrally managed by the Cisco FireSIGHT Management Center. Management Center provides security teams with comprehensive visibility into and control over activity within the network. Such visibility includes users, devices, communication between virtual machines, vulnerabilities, threats, client-side applications, files, and websites. Holistic, actionable indications of compromise (IoCs) correlate detailed network and endpoint event information and provide further visibility into malware infections.
- Management Center also provides content awareness with malware file trajectory that aids infection scoping and root cause determination to speed time to remediation.
- Cisco Security Manager provides scalable and centralized network operations workflow management. It integrates a powerful suite of capabilities; including policy and object management, event management, reporting, and troubleshooting for Cisco ASA firewall functions. For small-scale and simple deployments, the Cisco Adaptive Security Device Manager (ASDM) is available to provide on-device, GUI-based firewall network operations management.
- Cisco’s enterprise-class management tools help administrators reduce complexity with unmatched visibility and control across NGFW deployments.
- Cisco ASA with FirePOWER Services incorporates an integrated approach to threat defense, reducing capital and operating costs and administrative complexity. It smoothly integrates with the existing IT environment, work stream, and network fabric. The purpose-built appliance family is highly scalable, performs at up to multigigabit speeds, and provides consistent and robust security across branch, Internet edge, and data centers in both physical and virtual environments.
- With Cisco FireSIGHT Management Center, administrators can streamline operations to correlate threats, assess their impact, automatically tune security policy, and easily attribute user identities to security events. Management Center continually monitors how the network is changing over time. New threats are automatically assessed to determine which can affect your business. Response efforts are then focused on remediation, and network defenses are adapted to changing threat conditions. Critical security activities such as policy tuning are automated, saving time and effort, while protections and countermeasures are maintained in an optimal state.
- Cisco FireSIGHT Management Center integrates easily with third-party security solutions through the eStreamer API to streamline operation workflows and fit existing network fabrics.
- Site-to-site and remote access VPN and advanced clustering provide highly secure, high-performance access and high availability to help ensure business continuity.
- Granular Application Visibility and Control (AVC) supports more than 3,000 application-layer and risk-based controls that can launch tailored intrusion prevention system (IPS) threat detection policies to optimize security effectiveness.
- The industry-leading Cisco ASA with FirePOWER next-generation IPS (NGIPS) provides highly effective threat prevention and full contextual awareness of users, infrastructure, applications, and content to detect multivector threats and automate defense response.
- Reputation- and category-based URL filtering offer comprehensive alerting and control over suspicious web traffic and enforce policies on hundreds of millions of URLs in more than 80 categories.
- AMP provides industry-leading breach detection effectiveness, a low total cost of ownership, and superior protection value that helps you discover, understand, and stop malware and emerging threats missed by other security layers.
- The SonicWALL TZ series of next generation firewalls (NGFW) is ideally suited for any organization that requires enterprise-grade network protection.
- SonicWALL TZ series firewalls provide broad protection with advanced security services consisting of onbox and cloud-based anti-malware, anti-spyware, application control, intrusion prevention system (IPS), and URL filtering. To counter the trend of encrypted attacks, the SonicWALL TZ series has the processing power to inspect encrypted SSL connections against the latest threats.
- Backed by the SonicWALL Global Response Intelligent Defense (GRID) network, the SonicWALL TZ series delivers continuous updates to maintain a strong network defense against cybercriminals. The SonicWALL TZ series is able to scan every byte of every packet on all ports and protocols with almost zero latency and no file size limitations.
- The SonicWALL TZ series features Gigabit Ethernet ports, optional integrated 802.11ac wireless, IPSec and SSL VPN, failover through integrated 3G/4G support, load balancing and network segmentation. The SonicWALL TZ series UTM firewalls also provide fast, secure mobile access over Apple iOS, Google Android, Amazon Kindle, Windows, MacOS and Linux platforms.
- The SonicWALL Global Management System (GMS) enables centralized deployment and management of SonicWALL TZ series firewalls from a single system.
- Block more attacks with patent-pending Real-Time Deep Memory Inspection (RTDMITM) & Patented Real-Free Deep Packet Inspection (RFDPI®) technology
- Combine cloud-based and on-box threat prevention featuring multi-engine sandboxing
- Industry-validated high security effectiveness
- Get high-speed performance with 40-Gigabit Ethernet ports
- Security that scales to protect millions of encrypted connections
- Decrypt and inspect TLS/SSL and SSH traffic in real time
- Leverage powerful SonicOS operating system
- Gain application intelligence and control
- Segment your network into zones
- Deploy at the network edge or data center core
- Block more attacks with patent-pending Real-Time Deep Memory Inspection (RTDMITM) & Patented Real-Free Deep Packet Inspection (RFDPI®) technology
- Combine cloud-based and on-box threat prevention featuring multi-engine sandboxing
- industry-validated high security effectiveness
- Get high-speed performance with 40-Gigabit Ethernet ports
- Security that scales to protect millions of encrypted connections
- Decrypt and inspect TLS/SSL and SSH traffic in real time
- Leverage powerful SonicOS operating system
- Gain application intelligence and control
- Segment your network into zones
- Deploy at the network edge or data center core
- This breakthrough threat prevention performance allows organizations to run NSS Labs Recommended intrusion prevention and application control and VB100 certified antimalware capabilities for deeper inspection. Rich console views and reports together with a flexible policy engine provide the visibility and control to empower employees yet secure your enterprise.
- Finally, these features of the FortiGate FortiOS Network Security Platform are routinely validated by independent real-world tests and are consistently getting superior ratings in security effectiveness.
- This breakthrough threat prevention performance allows organizations to run NSS Labs Recommended intrusion prevention and application control and VB100 certified antimalware capabilities for deeper inspection. Rich console views and reports together with a flexible policy engine provide the visibility and control to empower employees yet secure your enterprise.
- Finally, these features of the FortiGate FortiOS Network Security Platform are routinely validated by independent real-world tests and are consistently getting superior ratings in security effectiveness.
- 5 times faster hardware accelerated next generation firewall offers best-in-class price/performance ratio
- Integrated high port density delivers maximum flexibility and scalability
- NSS Labs Recommended NGFW and NGIPS with consolidated security delivers top-rated protection
- Application control plus identity and device-based policy enforcement provides more granular protection
- Intuitive management interface enables broad and deep visibility that scales from a single FortiGate to thousands
- Stateful inspection firewall throughput :300 Mbps
- Stateful inspection firewall throughput (multiprotocol) :50 Gbps
- Concurrent firewall connections :55 million
- Firewall latency (UDP 64B microseconds):3.5
- New connections per second : 800,000
- IPsec VPN throughput (450B UDP L2L test) : 15 Gbps
- IPsec/Cisco AnyConnect/Apex site-to-site VPN peers :20,000
- Security contexts (included; maximum) :10; 250
- High availability: active/standby
- Firewall throughput : 59 Gbps
- IPS throughput : 26 Gbps
- Anti-malware throughput : 16 Gbps
- Full DPI throughput : 17 Gbps
- IMIX throughput : 14 Gbps
- Maximum DPI connections : 6,000,000
- New connections/sec : 430,000/sec
- Storage module : 2 x 480 GB
- High Performance, Reliability and Security
- 10x data center and 5x next generation performance
- Top rated security capabilities
- Flexible firewall personalities for core or edge deployment
- Low latency and IPv6 parity
- Next Generation Visibility and Control
- Powerful application and threat inspection
- Breakthrough performance, and superior cost per gigabit protected
- User- and device-based views and policies
- Freedom to add more functions like Advanced Threat
- Protection and Secure Web Gateway
- FortiOS 5, the most complete, battletested set of security functions to protect your network and data
- Industry-leading 10x data center firewall offers exceptional throughput and ultra-low latency
- Highly available and Virtual Domain (VDOM) support for multi-tenant data center environment
- Integrated high-speed 10 GE+ port delivers maximum flexibility and scalability
- Intuitive management interface enables broad and deep visibility and control
- NSS Labs Recommended consolidated security delivers top-rated protection
- Industry-leading 10x data center firewall offers exceptional throughput and ultra-low latency
- Highly available and Virtual Domain (VDOM) support for multi-tenant data center environment
- Integrated high-speed 10 GE+ port delivers maximum flexibility and scalability
- Intuitive management interface enables broad and deep visibility and control
- NSS Labs Recommended consolidated security delivers top-rated protection
- Performance and Reliability for High Bandwidth Networks
- Breakthrough IPv4 to IPv6 firewall performance parity
- Flexible firewall personalities enable deployment at the Edge or Core
- Compact 3U footprint conserves rack space and minimizes energy consumption
- Freedom to add integrated security technologies (such as IPS, App Control, VPN)
- Cloud-ready multi-tenant support and APIs for rapid orchestration
- FortiOS 5 delivers the most complete, battle-tested set of security functions to protect your network and data
- Flexible Deployment
- The FortiGate 3800D Series give you the flexibility to choose the firewall personality that best fits your requirements at the Edge or Core. You can take advantage of the high port density for physical segmentation of your network, as well as the virtual domains (VDOMs) for virtual segmentation.
- Industry-leading 10x data center firewall offers exceptional throughput and ultra-low latency
- Highly available and Virtual Domain (VDOM) support for multi-tenant data center environment
- Integrated high-speed 10 GE+ port delivers maximum flexibility and scalability
- Intuitive management interface enables broad and deep visibility and control
- NSS Labs Recommended consolidated security delivers top-rated protection
- Powered by SPU
- Custom SPU processors deliver the power you need to detect malicious content at multi-Gigabit speeds
- Other security technologies cannot protect against today’s wide range of content- and connection-based
- threats because they rely on general-purpose CPUs, causing a dangerous performance gap SPU processors provide the performance needed to block emerging threats, meet rigorous third-party certifications, and ensure that your network security solution does not become a network bottleneck
The new FortiGate 6000 NGFW appliances feature the latest Fortinet innovation, to deliver leading edge security, performance, and connectivity for the most demanding network needs. The 6000 series combines unprecedented threat protection and SSL inspection performance in an easy to manage, compact appliance.
- Delivers industry's best threat protection performance and ultra-low latency using purpose-built security processor (SPU) technology
- Unprecedented 1 Terabit/second network firewall throughput in an appliance form factor for FortiGate 3980E
- Provides industry-leading performance and protection for SSL encrypted traffic
- Independently tested and validated best security effectiveness and performance
- Received unparalleled third-party certifications from NSS Labs, ICSA, Virus Bulletin and AV Comparatives
- Delivers extensive routing, high-speed interfaces, and high performance VPN capabilities to address performance and connectivity needs of large-scale data center and cloud applications
- Enables flexible deployment such as Next Generation Firewall and Secure SD-WAN
- FIM modules are hot swappable interface modules that provide data and management interfaces, base
- backplane switching and fabric backplane session-aware load balancing for the chassis. The FIM modules
- include an integrated switch fabric and DP2 processors to load balance millions of data sessions over the chassis
- fabric backplane to FPM processor modules. The following FIM modules are available:
- The FIM-7901E includes thirty-two front panel 10GigE SFP+ fabric channel interfaces (A1 to A32). These interfaces are connected to 10Gbps networks. These interfaces can also be configured to operate as Gigabit Ethernet
- interfaces using SFP transceivers.
- The FIM-7904E includes eight front panel 40GigE QSFP+ fabric channel interfaces (B1 to B8). These interfaces are
- connected to 40Gbps networks. Using 40GBASE-SR4 multimode QSFP+ transceivers, each QSFP+ interface can
- also be split into four 10GBASE-SR interfaces and connected to 10Gbps networks.
- The FIM-7910E (shown in FIM modules on page 6) includes four front panel 100GigE CFP2 fabric channel
- interfaces (C1 to C4). These interfaces can be connected to 100Gbps networks. Using 100GBASE-SR10 multimode
- CFP2 transceivers, each CFP2 interface can also be split into ten 10GBASE-SR interfaces and connected to 10Gbps networks.
- The FIM-7920E includes four front panel 100GigE QSFP28 fabric channel interfaces (C1 to C4). These interfaces can be connected to 100Gbps networks. Using a 100GBASE-SR4 QSFP28 or 40GBASE-SR4 QSFP+ transceiver, each QSFP28 interface can also be split into four 10GBASE-SR interfaces and connected to 10Gbps networks
