   Lenovo Storage Dealers chennai, Hyderabad, tamilnadu
Lenovo D1212 Direct Attached Storage
Lenovo D1212 Direct Attached Storage showroom in chennai, velachery, anna nagar, tamilnadu
Form Factor :- 2U
Single/Dual Expansion Modules :- Dual 12Gb SAS standard (MiniSAS-HD SFF 8644), with active/active failover

Supported Drives:-
12 hot-swap SAS 3.5-inch drives: 900GB 10,000rpm HDDs (2.5-inch drive in 3.5-inch bay); 2TB, 4TB, 6TB, 8TB, or 10TB 7,200rpm NL HDDs*; 4TB 7,200rpm NL SED HDDs; 400GB, 10 DWD SSDs* (2.5-inch drive in 3.5-inch tray)

Storage Capacity (per D1212 enclosure—up to 8 enclosures supported per HBA port):-
Up to 10.8TB – 10,000rpm HDDs; Up to 120TB – 7,200rpm NL SAS HDDs*; Up to 48TB – 7,200rpm NL SAS SED HDDs; Up to 4.8TB SSDs

Expandability (via Daisy-Chain):-
Up to 8 D1212 units per SAS Chain

HBAs Supported:-
ThinkServer 8885e PCIe 12Gb SAS Adapter (PMC 8885E chipset); ThinkServer LSI 93008-e (12Gb; LSI SAS 31088); Lenovo N2225 SAS/SATA HBA (12Gb) Adapter for System x (12Gb; LSI SAS 3008); N2226 SAS/SATA HBA (12Gb) Adapter for System x (LSI SAS 3008); ServeRAID M5225-2GB SAS/SATA Controller for System x (LSI SAS 3108); Avago SAS 9300-8e Host Bus Adapter (12Gb; LSI SAS 3008); Avago SAS 9300-16e Host Bus Adapter (12Gb; LSI SAS 3008 x2); Avago SAS 9302-16e Host Bus Adapter (12Gb; LSI SAS 3008 x2);
Avago SAS 9302-16e Host Bus Adapter (12Gb; LSI SAS 3008 x2); Avago MegaRAID SAS 9380-8e LSI SAS3108); Avago MegaRAID SAS 9380-4i4e LSI SAS3108)

RAID Support:-
RAID 0, 1, 5, 6, 10, 50, 60 (HBA-dependent)

Power Supplies and Fans :-
Two 580W (1+1) hot-swap/redundant 80 Plus Gold power supplies; two integrated fans per power supply

Back Panel Connectors:-
Each expansion module (x2) includes 1 Ethernet management port, 3x MiniSAS HD Connector (SFF 8644), It can be configured as in/ingress or out/egress port by SAS zoning mode setting.

Form Factor / Dimensions / Weight:-
2U/Height: 87.9mm (3.5 in.); Width: 443mm (17 in.); Depth: 630mm (24.8 in.); Weight: max. 24kg (57.2lbs)

Limited Warranty
3- or 5-year Limited Warranty, 9x5 Next Business Day (upgradeable), or 9x5x4, or 24/7x4.

Call for Best Price
Lenovo D1224 Direct Attached Storage
Lenovo D1224 Direct Attached Storage showroom in chennai, velachery, anna nagar, tamilnadu
Form Factor :-
2U

Dual Expansion Modules:-
Dual 12Gb SAS standard (MiniSAS-HD SFF 8644), with active/active failover

Supported Drives:-
24 hot-swap SAS 2.5-inch drives: 300GB and 600GB 15,000rpm HDDs; 600GB, 900GB, 1.2TB, and 1.8TB 10,000rpm HDDs; 1.2TB 10k SED HDDs; 1TB and 2TB 7,200rpm NL HDDs; 400GB, 800GB, and 1.6TB 3 DWD SSD; 400GB, 800GB, and 1.6TB 10 DWD SSDs*; 800GB SED SSDs*; 3.84TB and 7.68TB 1DWD SSDs*

Storage Capacity (per D1224 enclosure—up to 8 enclosures supported per SAS Chain):-
Up to 14.4TB – 15,000rpm SAS HDDs; 43.2TB – 10,000rpm SAS HDDs; up to 28.88TB – 10,000rpm SAS SED HDDs; up to 48TB – 7,200rpm NL SAS HDDs; up to 184.32TB – SSDs; up to 19.2TB SED SSDs

Expandability (via Daisy-Chain) :-
Up to 8 D1224 units per SAS Chain

HBAs Supported:-
ThinkServer 8885e PCIe 12Gb SAS Adapter (PMC 8885E chipset); ThinkServer LSI 93008-e (12Gb; LSI SAS 31088); Lenovo N2225 SAS/SATA HBA (12Gb) Adapter for System x (12Gb; LSI SAS 3008); N2226 SAS/SATA HBA (12Gb) Adapter for System x (LSI SAS 3008); ServeRAID M5225-2GB SAS/SATA Controller for System x (LSI SAS 3108); Avago SAS 9300-8e Host Bus Adapter (12Gb; LSI SAS 3008); Avago SAS 9300-16e Host Bus Adapter (12Gb; LSI SAS 3008 x2);
Avago SAS 9302-16e Host Bus Adapter (12Gb; LSI SAS 3008 x2); Avago MegaRAID SAS 9380-8e LSI SAS3108); Avago MegaRAID SAS 9380-4i4e LSI SAS3108)

RAID Support:-
RAID-0, 1, 10, 5, 50, 6, 60 (HBA-dependent)

Power Supplies and Fans :-
Two 580W (1+1) hot-swap/redundant 80 Plus Gold power supplies; two integrated fans per power supply

Back Panel Connectors:-
Each expansion module (x2) includes one Ethernet management port, 3x MiniSAS HD Connector (SFF 8644), It can be configured as in/ingress or out/egress port by SAS zoning mode setting

Form Factor / Dimensions / Weight:-
2U/Height: 87.9mm (3.5 in.); Width: 443mm (17 in.); Depth: 630mm (24.8 in.)/Weight: max. 26kg (53lbs)

Limited Warranty:-
3- or 5-year Limited Warranty, 9x5 Next Business Day (upgradeable), or 9x5x4, or 24/7x4.
Call for Best Price
Lenovo D3284 Direct Attached Storage
Lenovo D3284 Direct Attached Storage showroom in chennai, velachery, anna nagar, tamilnadu
Form Factor :-
5U

Dual Expansion Modules:-
Dual 12Gb SAS standard, with active/active failover

Supported Drives :-
84x hot-swap SAS 3.5-inch drives:4TB, 6TB, 8TB, or 10TB 7,200rpm NL SAS HDDs; 400GB SSDs (2.5-inch drive in 3.5-inch tray)

Storage Capacity (per enclosure):-
Up to 840TB – 7,200rpm NL SAS HDDs; up to 33.6TB – SAS SSDs

Expandability (via Daisy-Chain) :-
Up to 4x D3284 enclosures per HBA

HBAs Supported:-
9380-4i4e SAS/SATA HBAs for System x; N2226 SAS/SATA HBAs for System x; ThinkServer 9300-8e PCIe 12Gb 8-Port External SAS Adapter by LSI

RAID Support:-
RAID-0, 1, 10, 5, 50, 6, 60 (HBA-dependent)
Power Supplies and Fans :-
2x 2214W (1+1) hot-swap/redundant 80 Plus Platinum power supplies; 5 hot-swap/redundant fans

Back Panel Connectors:-
Each expansion module (x2) includes: 4x ports: 3x 12Gbps Mini-SAS HD (SFF-8644) per ESM; 1x RJ45 Ethernet port for management

Form Factor / Dimensions / Weight:-
5U/Height: 219mm (9.5 in.); Width: 483mm (19 in. IEC60297 rack compliant); Depth: 933mm (36.75in.)/Weight: min. 64kg (141 lbs); max. 131kg (289 lbs)

Limited Warranty:-
3-year Limited Warranty, 9x5 Next Business Day Onsite (upgradeable)

Call for Best Price
