Extreme 5320 16P 2MXT 2X 16 Port Ethernet Switch

Brand: Extreme

Model No: 5320-16P-2MXT-2X

Product: 5320-16P-2MXT-2X 16 Port Rack Mountable Switch

Port Quantity: 16 x 10/100/1000BASE-T 802.3at (30W) ports; 2 x 1/2.5/5/10GBase-T uplink ports; 2 x 10Gb SFP+ uplink ports; Fanless mode; 1 x Serial console port (RJ-45); 1 x USB A ports for management or external USB flash; 1 x USB-C console port

Advanced Switching: Layer 3

Ports: 16 Ports

Switching Type: Gigabit Ethernet

Compliant Standards: IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3at, IEEE 802.3az

Features: Auto-sensing per device, Fanless, Full duplex mode, Half duplex mode, MACsec support, Mode button

Form Factor (Hubs & Switches)

Rack-mountable: MAC Address Table Size 32000 entries

Manageable: Yes

Max Units In A Stack: 8

PoE Budget: 180 watt

Power Over Ethernet (PoE): PoE

Remote Management: CLI

Status Indicators: Local, Power, Speed, System, Uplink

Subcategory: Network hubs and switches

QSFP Slots: 10 Gigabit SFP+ (uplink)

Interface Provided: 1 x console USB Type-C, 1 x serial (console) RJ-45, 1 x USB, 16 x 10/100/1000 Base-T RJ-45, 2 x 100/1000/2.5G/5G/10GBase-T RJ-45

Capacity: ACL entries (egress): 190, ACL entries (ingress): 512, Active VLANs: 4059, ARP table (IPv4): 4000, Fabric nodes: 300, IP router interfaces: 248, IPv4 routes: 1000, IPv6 neighbors: 4000, IPv6 routes: 500, L2VSN: 128, L3VSN: 8, Multicast (S,G,V): 4000, VRF instances: 8

Device Type: Internal power supply
