Dell UltraSharp U5226KW 52 Thunderbolt IPS Hub Monitor

Number of Screens: 1

Screen Size Class: 52" (132.08 cm)

Viewable Screen Size: 51.5" (130.81 cm)

Screen Mode: 6K

Panel Technology: In-plane Switching (IPS) Black Technology

Response Time Details: 5 ms GTG (Fast), 8 ms GTG

Aspect Ratio: 21:9

Pixel Pitch: 0.19644 mm x 0.19644 mm

Horizontal Viewing Angle: 178°

Vertical Viewing Angle: 178°

Mount Type: Panel Mount

HDCP Supported: Yes

Maximum Adjustable Height: 90 mm

Tilt Angle: -5° to 10°

Swivel Angle: -20° to 20°

Slant Angle: -2°/2°

Features: Internal Multi-Stream Transport (iMST), Anti-glare, Low Reflection, Eye Comfort Technology, Low Blue Light, Flicker-free, Colour Calibration, Security Lock, Cable Lock Slot, Ambient Light Sensor, Picture by Picture, Picture in Picture, Arsenic-free Glass, Mercury-free, BFR Free

PVC Free

Adjustable Stand: Yes

Stand Adjustments:

Height: Tilt, Slant, Swivel

Stand Included: Yes

Pivot: No

Curved Screen: Yes

Curvature: 4200R

Glass Hardness: 3H

Surface Treatment: Anti-glare Low Reflectance

Flicker Free: Yes

HDMI Feature Support: Variable Refresh Rate (VRR)

Video:

Maximum Resolution: 6144 x 2560 at 120Hz

Standard Refresh Rate: 120 Hz

Color Supported: 1.07 Billion Colors

Native Contrast Ratio: 2,000:1

Brightness: 400 cd/m2

Color Gamut: 99% DCI-P3 (CIE 1976), 100% sRGB (CIE 1931), 100% BT.709 (CIE 1931), 99% Display P3

Calibration Accuracy: E < 1.5

Pixel Per Inch (PPI): 129

Audio:

Number of Speakers: 2

Speakers: Yes

Speaker Output Power: 2 x 9 W

Interfaces/Ports:

Connectivity:

2 HDMI port/s (HDCP 2.2) (Supports up to 6144 x 2560, 120 Hz, VRR, , as specified in HDMI 2.1 (FRL))

2 DisplayPort 1.4 (HDCP 2.2) port/s

4 USB Type-A 10Gbps downstream port/s

3 USB-C 10Gbps upstream port/s

1 Thunderbolt 4 40Gbps upstream port/s (DisplayPort 1.4 Alt Mode, Power Delivery up to 140 W EPR)

1 RJ45 Ethernet port/s, 2.5GbE

1 USB Type-A 10Gbps downstream port/s with Battery Charging 1.2

2 USB-C 10Gbps downstream port/s, Power Delivery up to 27 W

Built-in Devices: USB Hub, KVM Switch

Microphone: No

Environmental Conditions:

Operating Temperature Range: 0°C to 40°C

Non-operating Temperature Range: -20°C to 60°C

Operating Humidity Range: 10% to 80% (Non-condensing)

Non-operating Humidity Range: 5% to 90% (Non-condensing)

Maximum Operating Altitude: 5 km

Maximum Non-operating Altitude: 12.19 km

Power Description:

Input Voltage Range: 100V AC to 240V AC

Operating Power Consumption: 63.60 W

Standby Power Consumption: 0.5 W

Off-Mode Power Consumption: 0.3 W

Frequency: 50 Hz, 60 Hz

Maximum Power Consumption: 430 W

Voltage Current: 5.50 A

Physical Characteristics:

VESA Mount Compatible: Yes

VESA Mount Standard:100 x 100, 200 x 100, 200 x 200

Color Family: Silver

Product Color: Platinum Silver

Height: 529.05 mm

Width: 1223.32 mm

Depth: 111.94 mm

Height with Stand: 666.79 mm

Width with Stand: 1223.32 mm

Depth with Stand: 255 mm

Compressed Height with Stand: 576.79 mm

Extended Height with Stand: 666.79 mm

Bezel Width (Top): 10.34 mm

Bezel Width (Bottom): 15.80 mm

Bezel Width (Left): 10.34 mm

Bezel Width (Right): 10.34 mm

Weight (Approximate): 12.95 kg

Stand Height: 666.79 mm

Stand Width: 1223.32 mm

Stand Depth: 255 mm

Weight with Stand (Approximate): 18.23 kg

Miscellaneous:

Package Contents: Monitor, Stand, QR Card, Safety, Environmental, and Regulatory Information

Certifications & Standards: Israel EE, CEL, Ukrain EE, Mexico EE, Ghana EE, GS Mark, Arsenic-Free glass and Mercury-Free for the panel only,BFR/PVC free monitor (excluding external cables),California CEC

Platform Supported: Windows, ThinOS, Linux, Mac

Energy Star: Yes

Country of Origin: China/Vietnam

TAA Compliant:

No

TCO Certified: Yes

Eye Comfort Certification: Yes

Eye Comfort Rating: 5 Star

Remote Asset Management

Dell Display and Peripheral Manager (DDPM)

Dell Device Management Console (DDMC)

Dell Color Management (DCM)

Cable Type Included

Power cable: 1 x DisplayPort 1.4 cable - 1.80 m, 1 x HDMI 2.1 cable - 1.80 m, 1 x USB-C to USB Type-A 10Gbps cable - 1.0 m, 1 x Thunderbolt 4 40Gbps cable - 2.0 m

Environmentally Friendly: Yes

Environmental Certification: China Environmental United Certification Center (CEC), Electronic Product Environmental Assessment Tool Climate+ (EPEAT Climate+),Electronic Product Environmental Assessment Tool Gold (EPEAT Gold)

TCO Certified 10.0, TCO Certified Edge

Energy Efficiency Certification: China Energy Conservation Program (CECP), ENERGY STAR 8.0

Energy Efficiency Compliance: Energy-related Products Directive Lot 5 (ErP Lot 5), Energy-related Products Directive (ErP), Korea Minimum Energy Performance Standards (MEPS)

Limited Warranty: 3 Year

Additional Warranty Information: 3-Year Advanced Exchange Service and Premium Panel Exchange
